Beehive Spring Kit w/ Titanium Retainers – Hyundai | G4KF

High-performance beehive valve spring kit with titanium retainers for Hyundai | G4KF, improving valve control, high-RPM stability, and durability.

Attributes
Spring Type	Beehive Valve Spring
Seat Pressure	67lbs @ 35.50mm
Retainer Material	Titanium

Specs
Outer Spring Od	27.70mm
Outer Spring Id	19.70mm
Inner Spring Od	23.20mm
Inner Spring Id	15.20mm
Seat Pressure	67lbs @ 35.50mm
Open Pressure	182lbs @ 11.50mm
Max Lift	13mm
Coil Bind	21.50mm
Safe Rpm Limit	8000
Retainer	ret-ts5.5/t9f-be
Retainer Qty	16
Seat Locator	seat-m1015-2
Seat Locator Qty	16
Kit Spring	spr-ts1012-be
Rate	10.40lbs/mm
Kit Spring Qty	16
